张力连接箱：PFXC141: 3 bse029997r1
Based on the available information, the ABB PFXC141 module with order number 3BSE029997R1 is a Tension Link Box or Junction Box.
Here’s a summary of the information in English:
Product Name: Tension Link Box PFXC141
Product Description: The ABB PFXC141 (part number 3BSE029997R1) is a junction box designed for connecting load cells in web tension measurement systems. It serves as an interface between the load cells and the tension electronics (like the PFEA series controllers). The link box simplifies the wiring and connection of multiple load cells to the control unit, providing organized terminals for signal and power connections. It ensures proper signal transmission and can offer features like parallel connection of load cells or signal trimming capabilities. The PFXC141 is designed for industrial environments and facilitates the installation and maintenance of web tension measurement systems.
Typical Product Parameters:
- Model: PFXC141
- Part Number: 3BSE029997R1
- Number of Load Cell Connections: Likely supports connections for multiple load cells (typically 2 or more; the exact number should be confirmed in the datasheet).
- Wiring Terminals: Provides terminals for load cell signal wires and excitation voltage.
- Connection Type: Parallel connection of load cells is a common application.
- Signal Output: Outputs combined or individual load cell signals to the tension controller.
Typical Specifications:
- Material: Likely a robust industrial material (e.g., metal or durable plastic).
- Mounting: Designed for industrial mounting (e.g., surface or DIN rail).
- Degree of Protection: IP rating suitable for industrial environments (the specific IP rating should be confirmed in the datasheet).
- Dimensions: Compact size for easy installation near the load cells. (Specific dimensions should be checked in the datasheet).
