The product is named ABB TU847 3BSE022462R1 Module Terminal Unit. ABB, a globally recognized leader in power and automation technologies, manufactures this module, which is widely used in industrial control and automation systems.
2. Product Description
2.1 General Function
The TU847 3BSE022462R1 is a Module Termination Unit (MTU) specifically designed for the redundant configuration of the field communication interface CI840/CI840A. It serves as a crucial link in industrial automation setups, enabling seamless communication and power distribution among various components. As a passive unit, it plays a pivotal role in establishing connections for power supply, the electrical module bus, two CI840/CI840A units, and incorporates two rotary switches for setting the station address within the range of 0 to 99. Additionally, it allows for the connection of a Module Bus optical port TB842 via TB806, expanding the communication capabilities within the system.
2.2 Key Features
- Mechanical Key Configuration: Four mechanical keys, with two keys for each position, are utilized to configure the MTU for the appropriate types of modules. Each key offers six positions, resulting in a comprehensive total of 36 different configuration options. This mechanical keying system provides a reliable and precise way to ensure that the correct module types are installed, preventing incorrect module insertions that could lead to system malfunctions.
