AB 1769-HSC
Product Description:
The Allen-Bradley 1769-HSC is a Compact I/O module designed to interface with high-frequency signaling devices. It is typically used for counter applications, totalizer requirements, and position monitoring and control. This module can directly interface with encoders, pulse outputs from transmitters, and fast sensing devices. It features quadrature (ABZ) differential inputs and sourcing DC outputs. The 1769-HSC is suitable for high-speed control applications such as flow control, measuring length, position, speed, frequency, or duration.
Key Characteristics:
- Two quadrature (ABZ) differential inputs, configurable for various modes (pulse/direction, up/down pulse, X1/X2/X4 encoder input).
- High-speed counter/encoder input frequency (1 MHz).
- Four sourcing DC outputs (5-30V DC).
- Twelve virtual (control bit) outputs.
- 32-bit count values (±2 billion counts).
- 21-bit rate values (±1 MHz).
- User-definable minimum and maximum count values.
- Individual counter reset function.
- User-definable preset.
- Linear or ring counter operation.
- Selectable input filters.
Product Parameters:
- Manufacturer: Allen-Bradley (Rockwell Automation)
- Part Number: 1769-HSC
- Series: CompactLogix
- Product Type: High Speed Counter/Encoder Module
- Number of Inputs: 2 quadrature (ABZ) differential inputs
