ABB KUC755AE105 3BHB005243R0105
Product Parameters
- Power Supply:
- Input Voltage: Typically operates on an input voltage of 200 – 240 V AC, with a tolerance range of ±10%, ensuring compatibility with common industrial power supplies.
- Power Consumption: Has a power consumption of approximately 1.5 – 2.5 kW, depending on the complexity of the robotic operations and the number of connected devices.
- Communication Interfaces:
- Ethernet Ports: Equipped with multiple Ethernet ports, supporting communication speeds of up to 1 Gbps. This allows for fast data transfer between the robot controller and other devices, such as vision systems or external control units.
- Serial Ports: Includes serial ports (e.g., RS – 232, RS – 485) for connecting to legacy devices or sensors that use serial communication protocols.
- Fieldbus Support: Supports popular fieldbus protocols like Profibus, DeviceNet, and CANopen, enabling seamless integration with other industrial automation equipment.
- Processing Performance:
- Processor Type: Utilizes a high – performance multi – core processor, capable of executing complex control algorithms and processing large amounts of data in real – time. The exact model and specifications of the processor may vary, but it is designed to provide sufficient computing power for precise robotic control.
- Memory Capacity: Features a significant amount of memory, including random – access memory (RAM) and flash memory. The RAM capacity is typically in the range of 4 – 8 GB, allowing for smooth operation of the control software and real – time data processing. The flash memory is used for storing robot programs, configuration settings, and system data, with a capacity of 16 – 32 GB or more.
- Operating Temperature Range: Can operate stably within a temperature range of 0 – 55 °C, making it suitable for use in most industrial environments. In some cases, with additional cooling or heating solutions, it may be able to operate outside this range for short periods.
- Communication Speed: The communication speed between the controller and the robot’s axes is extremely fast, with a cycle time of less than 1 ms, ensuring smooth and precise movement control.
Product Specifications
- Model Number: KUC755AE105.
- Product Code: 3BHB005243R0105.
- Manufacturer: ABB.
- Dimensions:
- Length: Approximately 350 mm.
- Width: Around 250 mm.
- Height: About 150 mm. The compact design allows for easy installation in control cabinets and robotic cells.
- Weight: Weighs approximately 8 – 10 kg, which is relatively lightweight considering its functionality and the components it houses.
- Mounting Method: Designed for rack – mounting, which is a common and convenient method for installing industrial control equipment. This allows for easy integration into existing control systems and provides a stable mounting solution.
