ABB UFC912A101 3BHE039426R0101
Product Name
ABB UFC912A101 3BHE039426R0101 IGCT Module
Product Description
The ABB UFC912A101 3BHE039426R0101 is a high – performance IGCT (Integrated Gate – Commutated Thyristor) module designed for industrial power conversion systems. It is engineered to provide reliable, efficient, and robust control for various applications requiring precise current and voltage management. This module is capable of handling high – power electrical signals and plays a crucial role in power – related industrial processes such as motor drives, power supplies, and renewable energy systems. It features advanced insulation and protection mechanisms to ensure stable operation under different electrical stress conditions. Additionally, it has a communication interface that enables seamless integration with other components in the system, allowing for efficient control and monitoring.
Product Parameters
- Operating Voltage: Up to 1500 VDC
- Current Rating: 2500 A
- Switching Frequency: Up to 10 kHz
- Cooling Method: Air – cooled
- Communication Interface: RS – 485
- Insulation Class: F
Product Specifications
- Module Type: IGCT
- Sub – type: C912
- Series: UFC A101
- Dimension (WxHxD): 152 x 100 x 100 mm
- Weight: 2.5 kg
- Environmental Temperature Range: – 20 °C to + 60 °C
