ABB 5SHY3545L0010/3BHB013088R0001
Product Parameters
- Nominal Voltage: 4500V. This high – voltage rating makes the module suitable for applications in high – voltage power transmission and distribution systems, as well as high – voltage industrial drives.
- Nominal Current: 3500A. The ability to handle such a large current is essential for high – power applications, such as large – scale motor drives and power converters.
- Peak Turn – On Gate Current: 1000A. This parameter determines the maximum current that can be applied to the gate of the thyristor to turn it on quickly and efficiently.
- Peak Turn – Off Gate Current: 1000A. It is crucial for rapidly switching off the thyristor, ensuring proper control of the electrical current flow.
- Turn – On Time: 1.5 μs. The short turn – on time enables quick response to control signals, allowing for efficient power switching in dynamic applications.
- Turn – Off Time: 1.5 μs. Similarly, the fast turn – off time is important for precise control and for minimizing power losses during the switching process.
- On – State Voltage Drop: 2.5V. A relatively low on – state voltage drop means less power is wasted as heat when the thyristor is conducting current, improving the overall efficiency of the power system.
- Off – State Leakage Current: 10mA. A low off – state leakage curre
nt ensures that minimal current flows through the module when it is in the off state, reducing power consumption and improving the accuracy of power control.
- Junction Temperature: 125 °C. This maximum junction temperature indicates the module’s ability to operate under high – temperature conditions, which is common in high – power applications.
Product Specifications
- Model Number: 5SHY3545L0010/3BHB013088R0001.
- Manufacturer: ABB.
