ABB AI810 3BSE008516R1
The ABB AI810 (part number 3BSE008516R1) is an analog input module belonging to the ABB S800 I/O system. It features 8 channels, each configurable as either a voltage or current input. The module provides a 12-bit resolution for analog-to-digital conversion. It is designed for single-ended inputs and requires a Module Termination Unit (TU) for field wiring connections. The AI810 is suitable for acquiring analog signals from various field transmitters in industrial automation applications.
Key Characteristics:
- 8 Analog Input Channels: Provides eight independent input channels.
- Configurable Input Type: Each channel can be configured for either voltage or current input.
- Voltage Input: Supports ranges such as 0-10V and 2-10V.
- Current Input: Supports ranges such as 0-2
- 0mA and 4-20mA. The current input is protected against short circuits to the transmitter supply (up to 30 V DC). Current limiting is achieved using a PTC resistor.
- 12-bit Resolution: Offers a resolution of 12 bits for the analog to digital conversion.
- Single-Ended Input: Designed for single-ended analog input signals.
- Requires Termination Unit: Needs a TU810, TU812, TU814, TU818, TU830, TU833, TU835, TU838, or TU850 Module Termination Unit for connectivity.
Product Parameters:
- Manufacturer: ABB
- Part Number: 3BSE008516R1
- ABB Type Designation: AI810
- Product Type: Analog Input Module
- Number of Input Channels: 8
