ABB PFTL101B 5.0KN 3BSE004191R1
Product Description
The ABB PFTL101B 5.0KN 3BSE004191R1 is a high – precision load cell engineered for diverse industrial applications. It plays a crucial role in accurately measuring forces, tensions, and weights within industrial processes.
This load cell is designed with advanced technology to provide reliable and accurate measurements. It uses high – quality strain gauge technology to convert mechanical forces into electrical signals, which can be easily processed and analyzed by control systems. This makes it suitable for applications where precise force or weight monitoring is essential, such as in manufacturing, packaging, and material handling industries.
The PFTL101B 5.0KN load cell is highly versatile. It can be used in both static and dynamic weighing scenarios. In static weighing, it ensures accurate determination of the weight of objects, while in dynamic weighing, it can quickly respond to changes in weight, for example, during the continuous flow of materials on a conveyor belt. It can also be used to measure tension in applications like wire and cable production, where maintaining the correct tension is vital for product quality.
Built with durability in mind, the load cell can withstand harsh industrial environments. It is constructed with materials that are resistant to corrosion, vibration, and shock, ensuring long – term reliable operation. Additionally, it has a high protection level, which further enhances its suitability for use in challenging conditions.
Product Parameters
- Rated Capacity: 5.0 kN (equivalent to approximately 1125 pounds – force), indicating the maximum force it is designed to measure accurately.
- Allowable Lateral Load: 30.0 kN (around 6750 pounds – force), which shows the maximum lateral force the load cell can endure without significant performance degradation.
- Overload Capacity in Measurement Direction: 25.0 kN (about 5625 pounds – force), demonstrating its ability to handle forces above the rated capacity to a certain extent without getting damaged.
- Spring Constant: 325 kN/mm (roughly 1857 kilopounds – force per inch), which is relevant for understanding the relationship between the applied force and the resulting displacement in the load cell’s elastic elements.
- Accuracy: ±0.25%, ensuring high – precision measurements. This level of accuracy makes it suitable for applications where even small variations in force or weight measurement can have a significant impact on the process.
- Non – linearity: ≤0.1%, indicating a very low deviation from a perfectly linear relationship between the applied force and the output signal, which is crucial for reliable and consistent measurements.
- Hysteresis: ≤0.1%, meaning that the difference between the output signal when the force is increasing and when it is decreasing is minimal, contributing to accurate and repeatable measurements.
- Zero Balance: ≤0.1%, ensuring that the output signal is close to zero when no force is applied, reducing errors in measurement.
- Output Signal: 2.0 mV/v, which is a standard output level that can be easily interfaced with most industrial control systems for further processing.
- Operating Temperature Range: – 10 °C to + 80 °C, allowing it to operate in a wide range of environmental temperatures commonly found in industrial settings.
- Storage Temperature Range: – 25 °C to + 85 °C, ensuring that the load cell can be stored in different temperature conditions without being damaged.
- Ingress Protection: IP65, providing good protection against dust and water jets, making it suitable for use in environments where there is a risk of dust or water splashing.
Product Specifications
- Model Number: PFTL101B 5.0KN 3BSE004191R1
- Manufacturer: ABB
- Module Type: Load Cell
- Dimensions: 25 mm x 25 mm x 100 mm, designed to be compact for easy integration into various industrial setups.
- Weight: 0.5 kg (as per some sources; other sources may vary, but this gives an approximate idea of its lightweight nature for easy handling and installation).
- Mounting: Likely designed with standard mounting options to facilitate easy installation in different applications, although specific details may vary depending on the actual design.
- Warranty: Usually comes with a 1 – year warranty (as per some product listings), ensuring product quality and providing users with peace of mind.
- Applications:
- Food Industry: Used for detecting the weight of packaging materials and containers, ensuring accurate filling and packaging.
- Chemical Industry: Employed for weighing and monitoring the weight of liquids and solids during production processes.
