EMERSON MVME61006E-0173R
Product Name
MVME61006E – 0173R VME Single – Board Computer Module
Product Description
The Emerson MVME61006E – 0173R is a high – performance, reliable embedded computer module designed for industrial automation and communication systems3. It is based on the PowerPC processor, integrating powerful computing capabilities, abundant I/O interfaces, and flexible expandability3. It is widely used in various industrial control, data acquisition, and communication systems3. This module combines the NXP MPC7457 PowerPC® processor and the AltiVec coprocessor, achieving an actual bandwidth of up to 320MB/s, which enables technological upgrades while maintaining backward compatibility6. It is the first VME – bus board card in the MVME6100 series designed with the Tundra Tsi148 VME – bus interface chip, providing dual – edge source – synchronous transmission (2eSST) VME – bus performance6.
Product Parameters
- Processor: It is equipped with an NXP® MPC7457 PowerPC® processor with a running frequency of up to 1.267GHz6. The 128 – bit AltiVec coprocessor is used for parallel processing, which is ideal for data – intensive applications6.
- Memory: It has up to 2GB of onboard DDR ECC memory and 128MB of flash memory to meet the requirements of demanding applications6.
- Communication Interface: It provides dual – gigabit Ethernet interfaces for high – performance networking6. In addition, it is equipped with two 33/66/100 MHz PMC – X interfaces, which allow the addition of industry – standard application – specific modules6.
- Bus Interface: The Tsi148 VMEbus interface chip is connected to a 133 – MHz PCI – X bus on the host bridge to ensure that the module can handle the 320 – MB/s data transfer rate of 2eSST6.
Product Specifications
- Model Number: MVME61006E – 0173R
- Manufacturer: Emerson
- Module Type: VME single – board computer module
- Dimensions: Usually, the dimensions of industrial – grade single – board computers are around 200mm×150mm×40mm, but the specific dimensions of this module need to
