EPRO PR6423/003-030-CN
Product Description
The EPRO PR6423/003 – 030 – CN is an eddy – current – based sensor system designed for critical turbomachinery applications. It combines an 8 – mm eddy current sensor with the CON021 eddy current signal converter1. This system is capable of precisely measuring shaft displacement, position, eccentricity, and speed1. It is widely used in steam, gas, and hydro turbines, compressors, gearboxes, pumps, and fans1. The sensor features non – contact measurement, a compact design, and easy installation, supporting threaded or flange – mount installation methods. The CON021 converter is compatible with various EPRO sensors and converts sensor signals for measurement and monitoring1.
Product Parameters1
- Measurement Range: Linear measurement range is 3.0 mm (118 mils).
- Initial Air Gap: 0.5 mm (20 mils).
- Incremental Scale Factor (ISF): ISO: 8 V/mm (203.2 mV/mil) ± 5 % @ temperature range 0 to 45 °C (+ 32 to + 113 °F).
- Deviation from Best Fit Straight Line (DSL): ± 0.025 mm (± 1 mil)
