FOXBORO 870ITEC-AYFNZ
Product Description
The FOXBORO 870ITEC – AYFNZ is a micro – processor – based, 2 – wire intelligent transmitter6. It is designed for electrodeless conductivity measurements6. It can convert electrochemical signals into digital signals and provide isolation to improve measurement accuracy and safety7. It features a human – machine interface that guides users through intuitive, menu – driven configuration, calibration, status – checking, and troubleshooting procedures6. Additionally, it offers on – line diagnostics for both the transmitter and sensor to indicate real – time measurement faults6. With its rugged field – mounted enclosure, it is suitable for various industrial environments such as chemical, petrochemical, power, environmental protection, and pharmaceutical industries7.
Product Parameters
- Measurement Range: 0 – 1000 mV7
- Accuracy: 0.05%7
- Isolation Voltage: 500 Vrms7
- Output Modes: HART, 4 – 20 mA, etc.7
- Temperature Range: – 20 °C to 85 °C7
- Communication Modes6: For the digital version (model c
- ode selection “-F”), it can operate in a low – speed (600 baud) digital mode with the digital signal superimposed over an analog 4 – 20 mA signal, or a high – speed (4800 baud) digital – only mode. Communication can be via the local human – machine interface, Foxboro PC – based configurator interface, or an I/A series system workstation.
- Power Supply: Usually 24 VDC
Product Specifications7
- Dimensions: 120 mm x 100 mm x 50 mm
- Weight: Approximately 0.5 kg
- Enclosure Material: Plastic
- Enclosure Protection Level: NEMA 4X and IEC IP65
