GE IS200BPVCG1BR1
Product Name: GE IS200BPVCG1BR1 Backplane ASM Interface Board
Product Description:
The GE IS200BPVCG1BR1 is a Backplane ASM (Assembly) Interface Board and a component of the GE Mark VI Speedtronic control system. The Mark VI system is a comprehensive solution for the management of heavy-duty steam and gas turbine systems, as well as wind turbine automated drive assemblies.
The IS200BPVCG1BR1 is designed to be installed in a rack system (specifically the 259B2460BTG2 Protection Rack) to support and connect multiple circuit boards within the Mark VI architecture. It features twenty-one female backplane connectors on its back portion, which interface with the connecting boards. The front portion of the board houses thirty-nine Input/Output (I/O) connectors, allowing for easy connection of ribbon cables and field wiring from outside the rack system. This design facilitates the transmission of data to and from the various boards attached to the backplane.
Key Features:
- Backplane Assembly Interface Board
- Part of the GE Mark VI Speedtronic system
- Designed for installation in a Protection Rack (259B2460BTG2)
- Features 21 female backplane connectors for board interconnection
- Equipped with 39 I/O connectors for external field wiring
- Facilitates data communication between boards within the rack
- Designed for easy access to I/O connectors from outside the rack
Product Parameters:
- Manufacturer: GE
- Part Number: IS200BPVCG1BR1
- Series: Mark VI Speedtronic
- Functional Acronym: BPVC
- Functional Description: Backplane ASM Interface
- Number of Backplane Connectors: 21 (female)
- Number of I/O Connectors: 39
- Weight: Approximately 0.8 kg
- Dimensions: Approximately 16 cm x 16 cm x 12 cm (packaging)
- Origin: United States (US)
