GE IS200BPVCG1BR1
Product Name
GE IS200BPVCG1BR1 Backplane ASM Interface Board
Product Description
The GE IS200BPVCG1BR1 is a printed circuit board (PCB) component specifically crafted for GE’s Mark VI Speedtronic series. This series, which has been developed over three decades, offers a reliable, scalable, and comprehensive solution for managing heavy – duty steam and gas turbine systems.
Functioning as a backplane board, the IS200BPVCG1BR1 is designed to be installed in a rack system that can accommodate and support multiple boards. It plays a crucial role in facilitating communication and data transfer within the Mark VI turbine control system. The board features a distinct layout. The rear half is equipped with twenty – one female backplane connectors. When inserted into the rack system, this part of the board is surrounded by tall walls that not only support but also lock connecting boards in place, ensuring a stable connection.
The other part of the board, which holds the input/output (I/O) connectors, is deliberately designed to be left exposed outside the rack system. This user – friendly design allows operators to easily connect ribbon connectors and their associated cabling to the board. With a total of thirty – nine I/O connectors, the IS200BPVCG1BR1 enables seamless data transfer to and from the boards attached to the backplanes. Additionally, the board includes fourteen stab – on connectors and six resistor network arrays. On the bottom side of the board, there are an additional thirty components labeled from L1 through L30. The board is clearly marked with both the manufacturer’s logo and the board number for easy identification.
Product Parameters
- Original Manufacturer: General Electric
- Series: Mark VI Speedtronic
- Functional Part Number: IS200BPVCG1BR1
- Functional Acronym: BPVC
- Functional Description: Backplane ASM Interface
- PCB Coating: Normal coating
- Functional Revision: 1B
Product Specifications
- Model Number: IS200BPVCG1BR1
- Manufacturer: GE
- Weight: Approximately 2 kgs
- Mounting: Designed for installation in a VME rack mounting assembly, as indicated by the attachment of a VME rack installation faceplate on its base PCB
- Connectors:
- Twenty – one female backplane connectors on the rear half
- Thirty – nine I/O connectors for data transfer
- Fourteen stab – on connectors
