GE SR469-P5-HI-A20-E
GE SR469 – P5 – HI – A20 – E Multilin 469 Digital Motor Protection System
Product Description
The GE SR469 – P5 – HI – A20 – E is an advanced motor management relay designed for medium – to – large motors4. It offers comprehensive protection, monitoring, and control functions to ensure the reliable and safe operation of motors in various industrial applications2.
This module is equipped with advanced algorithms that provide accurate motor protection2. It can detect and respond to a variety of fault conditions, including overload, overcurrent, voltage abnormalities, temperature issues, and differential faults2. It also offers real – time monitoring capabilities, providing detailed diagnostic information and event recording to facilitate easy troubleshooting and analysis2.
The SR469 – P5 – HI – A20 – E has a compact and rugged design, suitable for harsh industrial environments5. It features a conformal coating that protects against chemical exposure, and its enclosure rating and other certifications ensure reliable operation under demanding conditions4. Additionally, it is designed for easy installation and configuration, allowing users to quickly set up and customize the relay to meet their specific application requirements5.
Product Parameters
- Voltage Range (DC)4: 90 – 300 VDC
- Voltage Range (AC)4: 70 – 265 VAC
- Frequency Range3: 48 – 62 Hz
- Phase Current Input3: 5 A
- Analog Outputs4: 4 channels, 0 – 1 mA
- Digital Inputs4: 9 optically – isolated inputs
- RTD Inputs4: Multiple types, including 100 – ohm nickel, 120 – ohm nickel, 10 – ohm copper, and 100 – ohm platinum
- Operating Temperature Range4: – 40 °C to + 60 °C
- Storage Temperature Range4: – 40 °C to + 80 °C
- Overvoltage Category4: II
- Insulation Voltage4: 300 V
- Pollution Degree4: 2
Product Specifications
- Model Number2: SR469 – P5 – HI – A20 – E
- Manufacturer2: General Electric
- Series3: 469 Motor Management Relay
- Enclosure Rating4: 20 – X
- Certifications3: CE – certified
