Product Description:

The GE Fanuc VMIVME-7750 is a high-performance VMEbus single-board computer (SBC) designed for demanding industrial applications requiring real-time control and monitoring. It is a 6U form factor card built around the Intel Pentium III processor, offering significant processing power. The module supports up to 512 MB of PC133 SDRAM and features an internal AGP SVGA controller with display cache. It provides dual Ethernet interfaces for networking and includes a PMC expansion site for adding custom I/O or functionality.

Key Features:

• Processor: Up to 1.26 GHz Intel Pentium III with 512 KB advanced transfer cache
• Memory: Up to 512 MB PC133 SDRAM (via single SODIMM)
• Graphics: Internal AGP SVGA controller with 4 MB display cache
• Ethernet: Dual Ethernet interfaces (10BaseT and 100BaseTX)
• PMC Expansion: One PMC expansion site (5V signaling, types 1 and 2, 32-bit PCI bus, 33 MHz max)
• Mass Storage: Supports CompactFlash (up to 1 GB likely)
• Serial Ports: Two RS-232 serial ports
• VMEbus Interface: Compliant with VME Specification Rev. C.1, supporting various master/slave and interrupt handling modes.
• Timers: Two 16-bit timers and two 32-bit timers

Product Parameters:

• Manufacturer: GE Fanuc (now Abaco Systems)
• Series: VME-7750
• Product Type: Single Board Computer (SBC)
• Form Factor: 6U VMEbus
• Processor: Intel Pentium III (various speeds up to 1.26 GHz)
• Memory (RAM): Up to 512 MB PC133 SDRAM
• Ethernet: Dual 10/100Base-T Ethernet
• Serial Ports: 2 x RS-232
• PMC Slots: 1
• CompactFlash: Supports up to 1 GB (likely)
• Power Requirements: +5VDC (typical 6A, max 7A), +12VDC (typical 105mA, max 200mA), -12VDC (typical 50mA, max 75mA)
• Operating Temperature: 0 to 50 °C (Extended temperature options available for some sub-models)
• Storage Temperature: -25 to 80 °C
•
• Relative Humidity: 10% to 90%, non-condensing

Specifications:

• Product Type: Embedded Single Board Computer
• Bus Architecture: VMEbus
• Dimensions: Height 9.2 in (233.4mm), Depth 6.3 in (160mm), Thickness 0.8 in (20.3mm)
• VMEbus Interface: A16/A24/A32 addressing, D8/D16/D32/BLT/MBLT/2eVME data transfer
• Interrupt Handler: Programmable to respond to any or all VMEbus IRQ* lines (IH1 to IH7)
• Interrupter: Programmable, IRQ7* to IRQ1*
• Timers: Two 16-bit and two 32-bit software programmable timers
• Watchdog Timer: Software programmable
• BIOS: Includes capability to boot from Flash memory
• Operating Systems Support: Windows XP, VxWorks, Solaris, QNX, LynxOS, Linux (depending on the specific configuration)

Please Note: There might be variations in the exact specifications depending on the specific sub-model and configuration of the GE Fanuc VMIVME-7750 module. Always refer to the official product documentation and datasheets from Abaco Systems for the most accurate details for your specific unit. This product entered a Restricted Production Phase (RPP) in 2009, so availability for new installations might be limited.
