HONEYWELL CC-TDIL01
Product Name
HONEYWELL CC – TDIL01 Digital Input Module
Product Description
The HONEYWELL CC – TDIL01 is a digital input module designed for use with Honeywell’s Experion series C control system, especially within the Honeywell C300 controller series6. It is used to receive digital signals from external devices such as switches, push – buttons, and sensors6. It reads the digital signals and transmits that information to the control system4. With its robust design, it ensures reliable data acquisition and high – speed input processing6. It also features diagnostic capabilities that enable real – time signal monitoring and error detection, ensuring optimal system performance6. Moreover, it can operate within a wide temperature range ( – 40 °C to 85 °C ) and is resistant to vibration and shock, making it suitable for harsh industrial environments4.
Product Parameters
- Input Type: Single 24V DC digital input signal4.
- Galvanic Isolation: 1500V AC rms or ± 1500V DC between any input terminal and common, with optical isolation technique2.
- DI Power Voltage Range: On – sense voltage/current is 18 – 30V DC, 13V DC (min) or 3mA (min); off – sense voltage/current is 5V DC (max) or 1.2mA (max)2.
- Input Impedance: 4.2kΩ2.
- Absolute Delay across Input Filter and Isolation: 5ms ± 20%2.
- Field Resistance for Guaranteed On Condition: 300Ω max @ 15V DC2.
- Field Resistance for Guaranteed Off Condition: 30kΩ min @ 30V DC2.
Product Specifications
- Number of Channels: Multiple independent digital input channels6.
- Communication: Integrates with various communication protocols commonly used in industrial automation4.
- Mounting Type: Rack – mounted within the Honeywell C300 system6.
- Weight: Approximately 1 kg6.
- Operating Temperature Range: – 40 °C to 85 °C4.
