HONEYWELL FS-QPP-0002
HONEYWELL FS – QPP – 0002 Enhanced Performance Quad Processor Pack
Product Description
The HONEYWELL FS – QPP – 0002 is a high – performance quad – processor module tailored for use within safety – critical systems, such as the Safety Manager systems. It assumes a pivotal role in controlling and managing all system operations, guaranteeing secure process control and system diagnostics.
This module features four processors working in tandem, which provides substantial processing power for real – time control in complex industrial scenarios. The design is rugged, ensuring it can endure harsh industrial environments, including extreme temperatures, vibrations, and electrical interferences. It also supports versatile communication protocols, allowing seamless integration with other components in the industrial automation ecosystem.
In terms of its safety – related functions, the FS – QPP – 0002 is designed to run applications up to and including SIL3 (Safety Integrity Level 3) without time limitations. This makes it highly suitable for high – risk applications where safety is of utmost importance, such as in the oil and gas, chemical processing, and power generation industries.
The module is equipped with comprehensive self – test and diagnostic routines. These functions can detect hardware faults at an early stage, achieving diagnostic coverage of over 99%, which is crucial for SIL3 – compliant applications. It also includes a fully testable watchdog mechanism that constantly monitors the processor’s performance. In case of any anomalies, the watchdog ensures that the system either recovers gracefully or initiates a safe shutdown procedure to prevent potential hazards. Additionally, it monitors the internal temperature to avoid overheating and maintain stable operation, and has a real – time clock to ensure accurate and consistent time – sensitive operations across the system.
Product Parameters
- Processor: Four 667 MHz PowerPC 750 processors, delivering high – performance processing capabilities for safety – critical applications.
- Memory:
- 2 × 2 MB flash memory for storing system and application programs.
- 2 × 256 KB SRAM (battery – backed) for I/O, markers, counters, timers, and registers.
- 2 × 512 KB SRAM for data exchange with other control processors.
- 1 × 16 MB flash memory for backup purposes.
- Communication Interfaces:
- Two Ethernet ports for high – speed network connectivity, enabling data transfer and communication with other network – enabled devices in the system.
- One serial port, which can be used for connecting to legacy devices or for specific communication requirements that rely on serial communication protocols.
- One USB port, offering additional connectivity options, such as for easy configuration or data transfer.
- Power Supply: Input voltage is 24V DC.
- Operating Temperature: Can operate in the temperature range of – 5 °C to + 70 °C, making it adaptable to a wide variety of industrial environments.
- Diagnostics: Provides more than 99% diagnostic coverage, ensuring early detection of hardware faults.
- Watchdog: Equipped with a fully testable watchdog to monitor processor performance.
- Temperature Monitoring: Monitors internal temperature to prevent overheating.
- Real – Time Clock: Ensures accurate time – sensitive operations.
Product Specifications
- Model Number: FS – QPP – 0002
- Manufacturer: HONEYWELL
- Module Type: Quad – Processor Module
- Dimensions:
- Length: 176 mm
- Width: 88.5 mm
- Height: 212 mm
- Weight: 1.3 kg
- Approvals: Has approvals such as CE, UL, CSA, TUV, FM, indicating compliance with international safety and quality standards.
