The product is named GE Fanuc IC698CHS009 Communication Interface Module. It is developed by GE Fanuc, a prominent player in industrial automation and control systems.
2. Product Description
2.1 General Function
The IC698CHS009 is a high – performance communication interface module designed for seamless integration into GE Fanuc’s PACSystems RX3i platform. Its primary function is to enable reliable data exchange between the PACSystems controller and external devices or networks. This module supports critical communication protocols such as Ethernet/IP and DeviceNet, making it ideal for industrial applications requiring real – time data transfer, remote monitoring, and distributed control.
2.2 Key Features
- Dual Communication Ports: Equipped with both Ethernet/IP and DeviceNet ports, the module allows simultaneous communication over two distinct networks. This dual – port configuration enhances system flexibility, enabling connections to multiple devices or subnetworks without additional hardware.
- High – Speed Data Transfer: The Ethernet/IP port supports data rates up to 100 Mbps, ensuring rapid transmission of critical process data. The DeviceNet port, operating at speeds up to 500 kbps, provides reliable communication for industrial sensors and actuators.
- Redundancy Support: Designed for mission – critical applications, the module supports hot – swap redundancy configurations. This feature ensures continuous operation even during module replacement or maintenance, minimizing downtime in industrial processes.
- Advanced Diagnostics: Built – in diagnostic tools provide real – time monitoring of network status, communication errors, and device health. This proactive approach to system management simplifies troubleshooting and reduces maintenance time.
- Compact Design: With a 3U form factor, the module occupies minimal space in the control rack, optimizing panel real estate while maintaining high performance.
2.3 Application Scenarios
- Manufacturing Automation: Ideal for controlling robotic arms, conveyor systems, and assembly lines in automotive, food processing, and electronics manufacturing.
- Process Control: Used in chemical plants, water treatment facilities, and power generation stations to monitor and regulate critical processes.
- Material Handling: Enables seamless communication between Programmable Automation Controllers (PACs) and smart conveyors, AGVs (Automated Guided Vehicles), and warehouse management systems.
- Energy Management: Supports integration of renewable energy sources (e.g., wind turbines, solar farms) into industrial grids through real – time data exchange.
3. Product Parameters
3.1 Electrical Parameters
- Power Supply: 24 VDC (±10%)
- Power Consumption: ≤10 W
- Input/Output Signals: Digital I/O signals compatible with standard industrial sensors and actuators
- Isolation: 500 Vrms signal isolation
