JDSU 2213 – 75TSLKTB High – Performance Air – Cooled Argon Ion Laser Module
Product Description
The JDSU 2213 – 75TSLKTB is a high – performance air – cooled argon ion laser module. It is designed to meet the demands of complex and high – resolution OEM applications. This module incorporates advanced technology and components to ensure reliable and efficient operation.
With a focus on providing stable laser output, it features a metal – ceramic discharge tube with hard – sealed internal mirrors. This design not only extends the laser’s lifespan but also significantly reduces the need for field optic cleaning. The discharge tubes can be vacuum – baked at high temperatures, effectively eliminating contamination and enhancing the overall performance and reliability of the module.
The 2213 – 75TSLKTB is well – suited for applications where precise beam quality and consistent performance are crucial. Its axial airflow and symmetric design at the top of the cylindrical laser contribute to excellent mechanical packaging, ensuring high – stability beam pointing and rapid warm – up times. Additionally, the use of flexible piping between the laser head and the blower assembly minimizes mechanical vibrations caused by the blower, further enhancing the laser’s performance.
Product Parameters
- Wavelength: 488 nm. This specific wavelength makes it suitable for a variety of applications that require light at this particular frequency.
- Output Power: 75 mW. The module provides a relatively high output power, enabling it to handle tasks that demand sufficient laser energy.
- Beam Diameter: 1.2 mm. The defined beam diameter helps in accurately targeting the laser beam in specific applications.
- Divergence: < 1.2 mrad. Low divergence ensures that the laser beam remains focused over longer distances, maintaining its intensity and precision.
- Lifetime: > 10,000 hours. The long lifetime of the module reduces maintenance and replacement costs, making it a cost – effective choice for long – term use.
- Stability: < 0.1% RMS. High stability guarantees that the laser output remains consistent, which is vital for applications such as scientific research and industrial manufacturing where precision is key.
- Noise: < 2% RMS. Low noise levels ensure that the laser output is clean and does not interfere with sensitive measurements or processes.
Product Specifications
- Model Number: 2213 – 75TSLKTB
- Manufacturer: JDSU (now part of Lumentum)
- Laser Type: Air – cooled argon ion laser
- Beam Quality: High, with M2 < 1.2, indicating a near – diffraction – limited beam for high – precision applications.
- Emission Mode: TEM00, which provides a single – mode, high – quality beam.
- Operating Temperature: 0 °C to 50 °C. This temperature range allows for operation in a variety of environments, from relatively cool indoor settings to slightly warmer industrial or laboratory conditions.
- Storage Temperature: – 20 °C to 70 °C. The wide storage temperature range ensures that the module can be stored safely in different climates without being damaged.
