MOX12-P3509 B 80026-173-23
Product Name
The full name of the product is Absopulse MOX12 – P3509 B 80026 – 173 – 23 Power Supply Module. It is a power – related module designed and produced by Absopulse for industrial applications.
Product Description
- General Function: This is a DC – DC power supply module used to convert one DC power source to another DC power source that meets the requirements of specific applications, providing stable DC voltage output for various electronic devices1. It is mainly used in industrial automation, railway, telecommunications, military and other fields to ensure the normal operation of equipment and systems1.
- Key Features1:
- High – efficiency Conversion: It adopts advanced power conversion technology and high – efficiency components to reduce energy loss and heat generation, improving energy utilization efficiency.
- Wide Input Voltage Range: The module can adapt to a certain range of input voltage changes, usually with an input voltage range of 42 – 258 VDC, which can ensure stable power output under different power supply conditions.
- Multiple Outputs: It provides multiple output voltages, including ±5 VDC/10 A, ±15 VDC/1 A, +12 VDC/1 A, +24 VDC/2 A, ±24 VDC/1 A, etc., which can meet the power supply needs of different electronic devices.
- Customizability: Voltage and current specifications, output interface types, etc. can be customized according to specific needs to better adapt to different application scenarios.
- Reliability and Stability: The internal components have passed strict quality control and durability tests, with a long service life. It has stable power output and is suitable for various harsh conditions, such as high temperature, humidity, vibration and electromagnetic interference.
- Compact and Light – weight: It has a small volume and light weight, which is easy to integrate into various electronic devices and systems, saving installation space.
Product Parameters1
- Input Voltage: 42 – 258 VDC, maximum 8 A.
- Output Voltage: COM1: ±5 VDC/10 A; COM1: ±15 VDC/1 A; COM1: +12 VDC/1 A; COM5: +24 VDC/2 A; COM2: ±24 VDC/1 A; COM3: +15 VDC/1 A; COM4: +15 VDC/2 A.
Product Specifications
- Physical Dimensions: 140 mm×100 mm×75 mm.
- Weight: 1.2 kg.
- Operating Temperature Range: – 20 °C to +70 °C.
- Input Frequency: 47 – 63 Hz.
