NI PXIE-5105
Product Name
NI PXIe – 5105 60 MHz, 8 – Channel, 12 – bit PXI Oscilloscope1.
Product Description
The NI PXIe – 5105 is a high – performance data acquisition module designed for use in PXI – based measurement and control systems. It is mainly used for applications that require high – speed, high – resolution sampling of electrical signals, such as in research and development, test and measurement, and industrial automation. This module integrates eight channels, each of which can sample analog signals with a resolution of 12 bits, enabling accurate capture of signal details. With a bandwidth of 60 MHz, it can effectively measure and analyze signals within this frequency range. It features high – speed data transfer capabilities, allowing for efficient transfer of sampled data to the host computer or other components in the PXI system for further processing and analysis. Additionally, it offers good synchronization and triggering capabilities, which can be easily integrated with other PXI modules to build complex multi – channel measurement systems.
Product Parameters
- Bandwidth: 60 MHz1.
- Sampling Rate: Not specified in the common information, but generally, it should be able to meet the requirements of high – speed sampling within the bandwidth range.
- Resolution: 12 bits1.
- Number of Channels: 8 channels1.
- Input Range: The specific input range is not provided in the general description. However, it is usually designed to handle common analog signal levels in industrial and laboratory applications, such as ±5 V or ±10 V.
Product Specifications
- Model Number: PXIe – 5105.
- Product Series: PXIe.
- Manufacturer: National Instruments (NI).
