PFTL 101A-2.0kN，称重传感器3BSE004172R1
Product Name
ABB PFTL 101A – 2.0kN Load Cell
Product Description
The ABB PFTL 101A – 2.0kN is a load cell designed for precise force measurement in various industrial applications4. It is part of the PFT100 series, manufactured by ABB in Sweden2. This module is based on the non – contact magnetostrictive NOVOSTRICTIVE measurement technology, which ensures high – precision and reliable force measurement3. It is suitable for use in harsh industrial environments, with excellent resistance to shock and vibration3. With a compact and robust design, it can be easily integrated into different systems and machinery4. The load cell provides standard current or voltage signal output, and can be programmed manually through Teach – In positioning3. In addition, it can be equipped with optional electrical isolation according to user requirements3.
Product Parameters3
- Measurement Range: 2.0 kN
- Output Signal: Analog current output of 4 – 20 mA
- Power Supply: 24 VDC (operating range 19 – 30 VDC)
- Current Consumption: ≤ 100 mA
- Accuracy: Absolute linearity ≤ ± 0.02 % F.S. (minimum ± 50 µm), repeatability ≤ 0.03% F.S.
- Resolution: 16 – bit
- Temperature Coefficient: < 30 ppm/K
- Insulation Resistance: ≥ 10 MΩ at 500 VDC
- Working Temperature Range: – 40 – + 85 °C
- Storage Temperature Range: – 40 – + 105 °C
- Working Humidity Range: 0 – 95 % R.H. (non – condensing)
Product Specifications3
- Model Number: PFTL 101A – 2.0kN, 3BSE004172R1
- Manufacturer: ABB
- Dimensions: 30 cm * 20 cm * 20 cm
- Net Weight: 10 kg
- Mechanical Structure: Rugged enclosure
- Electrical Interface: Analog interface
- Output Cable or Plug: Optional
- Protection Class: IP67 / IP68
- Mounting: Adjustable clamp
