ABB 5SHY4045L0001 3BHB018162R0001
Product Description
The ABB 5SHY4045L0001 3BHB018162R0001 IGCT module is a high – performance power semiconductor device designed for power electronic conversion equipment, including power inverters and power electronic converters3. It combines the advantages of IGBTs and GTOs, offering an efficient and reliable power conversion solution3.
Featuring an integrated gate – drive circuit, it enables high – precision control5. The modular design makes it easy to install and maintain5. This module is capable of handling high – voltage and high – current DC power control, with stable power supply and high – control accuracy5. It can operate stably in harsh working environments such as high – voltage, high – temperature, and high – humidity conditions, and is widely used in DC power control applications in fields such as power, metallurgy, petrochemical, mining, rail transit, and automotive manufacturing5.
Product Parameters
- Rated Voltage: It can handle high – voltage levels, suitable for applications in the medium – to – high – voltage range.
- Rated Current: Capable of dealing with high – current loads, typically in the range of several kilo – amperes.
- Supply Voltage: Usually 115 – 240V1.
- Interface Type: Terminal interface1.
- Communication Protocol: Supports relevant industrial communication protocols for seamless integration with other control systems.
- IGCT Technology: Utilizes advanced integrated gate – commutated thyristor technology, which provides high – speed switching capabilities, low power consumption, and high reliability13.
Product Specifications
- Dimensions: The specific dimensions are in line with the original factory standards, which may vary depending on different packaging and installation requirements.
- Weight: Approximately 2.78 kg1.
- Environmental Compliance: Complies with relevant international standards and directives, such as RoHS
