GE DS200DCFBG1BJB
Product Description
The DS200DCFBG1BJB is a power board component manufactured by General Electric and is part of the Mark V Speedtronic system4. It is designed to provide control – level power for drives and cabinet fans in applications such as EX2000, DC2000, FC2000, GF2000, ME2000, CB2000, and AC2000 IGBT drives4. This board consists of motor excitation power, drive, AC/DC monitoring, and control – level power circuits1. The twelve jumpers and seven DIP switches on the circuit board provide users with configurable system options1. Additionally, it features a neon light to indicate a blown fuse in the 115 VAC line, and two LED indicators to show blown fuses in the + 24 VDC and – 24 VDC lines3.
Product Parameters
- Rated Voltage: 38 – 115 VAC1. The control power can also be 50 – 300 VDC / 40 – 265 VAC2.
- Interface Type: It has multiple I/O connectors, including 1PL – 1 to 1PL – 40, 2PL – 1 to 2PL – 9, 4PL – 1 to 4PL – 5, and 5PL – 1 to 5PL – 264.
- Configuration: Equipped with seven 4 – bit DIP switch devices and twelve configurable jumpers3.
Product Specifications
- Board Dimensions: It is a large rectangular circuit board, and the specific dimensions are subject to the original factory standards.
- Component Layout: A large number of components are surface – mounted on the board, including voltage and current feedback VCO circuits, motor voltage attenuation circuits, AC line magnetization and zero – crossing circuits, contactor drive circuits, field/armature SCR firing circuits, test points, fuses, resistance networks and resistors, capacitors, transistors, heat sinks, transformers, and relays4.
