VDE0611
WAGO VDE0611 Industrial DIN – Rail Terminal Block with Surge Protection
2. Product Description
The WAGO VDE0611 is a high – quality and reliable module designed for industrial applications. It serves as a crucial component in ensuring secure and stable electrical connections within industrial control systems. This module is especially well – suited for environments where electrical safety and performance are of utmost importance, such as in manufacturing plants, power generation facilities, and industrial automation setups.
2.1 Voltage Monitoring and Protection
Functioning as a voltage monitoring module, the VDE0611 keeps a close eye on the electrical voltage levels. It is designed to protect connected devices from potentially damaging voltage surges and spikes. With a response time of less than 1 nanosecond, it can react almost instantaneously when a surge occurs. This rapid response helps to safeguard valuable industrial equipment, preventing malfunctions and costly repairs.
2.2 Robust Construction for Harsh Environments
Built with durability in mind, the VDE0611 features a rugged construction. The housing is made of polycarbonate, which allows it to withstand harsh industrial conditions. It can operate within a wide temperature range, from – 25 °C to + 55 °C during normal operation and can endure storage temperatures ranging from – 40 °C to + 85 °C. Additionally, it can tolerate vibrations and electrical noise commonly found in industrial settings, ensuring consistent performance over time.
2.3 Easy Installation and Connection
The module comes with an innovative push – in connection technology, which simplifies the wire – insertion process. Users can insert wires quickly and easily without the need for additional tools, ensuring a secure electrical connection. It also has a cage clamp terminal type, which further enhances the stability of the connection. This makes the installation process more efficient, saving both time and effort during setup and maintenance.
2.4 Compliance with International Standards
The VDE0611 has obtained certifications from VDE, CE, and UL. These certifications indicate that the module meets strict international safety and quality standards. The VDE approval, in particular, is a mark of high – quality electrical safety, ensuring that the module can be used with confidence in industrial applications worldwide.
3. Product Parameters
- Rated Voltage: AC 230V
- Frequency Range: 50/60 Hz
- Current Rating: Up to 10 A
- Protection Class: Class I
- Contact Form: NO (Normally Open)
- Number of Poles: 1P
- Connection Technology: Cage clamp with push – in connection for easy wire insertion
- Wire Gauge Range: 0.08 to 2.5 mm²
- Operating Temperature Range: – 25 °C to + 55 °C
- Storage Temperature Range: – 40 °C to + 85 °C
- Energy Absorption Capacity: Up to 12 kJ, enabling it to handle multiple surges without failure
- Response Time: Less than 1 nanosecond for rapid protection against voltage surges
- Certifications: VDE, CE, UL
- Communication Interface: Modbus RTU/TCP, allowing for seamless integration with other industrial control systems for monitoring and control purposes
4. Product Specifications
- Model: VDE0611
- Brand: WAGO
- Type: Relay terminal with surge protection
- Mounting Type: DIN – rail, which allows for easy installation in standard industrial control panels
- Dimensions: Width: 11.5 mm, Height: 69.8 mm, Depth: 100 mm
- Weight: 32.298 g
