TRICONEX 3503E
Product Name: Triconex 3503E Digital Input Module
Product Description:
The Triconex 3503E is a Triple Modular Redundant (TMR) Digital Input (DI) module designed for use in EcoStruxure Triconex Safety Instrumented Systems (SIS). It is a crucial component for interfacing digital signals from field devices such as switches and sensors to the Triconex safety controller. The TMR architecture ensures high reliability and fault tolerance, making it suitable for safety-critical applications. The module features 32 input channels, commoned in groups of 8.
Key Features:
- Triple Modular Redundancy (TMR): Ensures continuous operation and fault tolerance.
- Digital Input (DI) Module: Interfaces with digital field signals.
- Number of Channels: 32 inputs, commoned in groups of 8.
- Voltage Compatibility: Typically supports 24 VDC or 24 VAC digital signals.
- Input Frequency Range: DC or 47-63 Hz.
- Galvanic Isolation: Provides electrical isolation between input channels and the control system.
- SIL Certified: Suitable for use in safety-critical applications, typically compliant with SIL3 standards (verify with the specific datasheet).
Product Parameters:
- Manufacturer: Triconex (Schneider Electric)
- Series: EcoStruxure Triconex
- Module Type: Digital Input (DI) Module
- Number of Input Points: 32 (commoned in groups of 8)
- Input Voltage Range: Typically 20-42.5 VDC or 24 VAC (verify with datasheet)
- Maximum Voltage: Typically 42.5 VDC/VAC (verify with datasheet)
- Weight: Approximately 0.8 kg to 2.06 kg (verify with the specific datasheet)
- Dimensions: (Standard Triconex module size – verify with the specific datasheet)
Specifications:
- Product Type: Digital Input Module for Safety Instrumented Systems (SIS)
- Technology: Triple Modular Redundancy (TMR)
- Application: Interfacing digital signals from field devices to the Triconex SIS controller in safety-critical applications.
- Operating Temperature: -40°C to +70°C (-40°F to +158°F) (verify with datasheet)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F) (verify with datasheet)
- Operating Humidity: 5% to 95% RH (non-condensing) (verify with datasheet)
- Certifications: SIL certified (refer to the specific Triconex system certification).
Please Note: The Triconex 3503E is a specific digital input module within the Triconex SIS family. For the most accurate and detailed product name, description, parameters, and
