TRICONEX 3805E
Product Name: Triconex 3805E Analog Output Module
Product Description:
The Triconex 3805E is an Analog Output (AO) module designed for use in EcoStruxure Triconex Safety Instrumented Systems (SIS). As part of the highly reliable and fault-tolerant Triconex system, it utilizes Triple Modular Redundancy (TMR) to ensure continuous and safe operation in critical industrial processes. This module provides analog output signals, typically current signals (e.g., 4-20 mA), to control analog final elements such as control valves and actuators in safety-critical applications.
Key Features:
- Triple Modular Redundancy (TMR): Provides fault tolerance and high availability.
- Analog Output (AO) Module: Controls analog final elements in safety systems.
- Current Output: Typically provides 8 channels of 4-20 mA analog output.
- Resolution: 12-bit resolution (as indicated by some sources).
- DC Coupled: Direct current coupled output.
- Enhanced Diagnostics: Includes built-in diagnostics for fault detection.
Product Parameters (Specific parameters may vary. Consult the official datasheet for the exact version you have):
- Manufacturer: Schneider Electric (formerly Triconex / Invensys)
- Series: EcoStruxure Triconex
- Module Type: Analog Output (AO) Module
- Number of Channels: 8
- Output Type: Analog Current
- Output Range: 4-20 mA
- Resolution: 12-bit (verify with datasheet)
- Weight: Approximately 2.7 kg (5.95 lbs)
