YASKAWA JAPMC-IO2301-E
The YASKAWA JAPMC-IO2301-E is a digital input/output module. It provides 16 digital inputs and 16 digital outputs. The inputs are configurable for 24 VDC sinking or sourcing, offering flexibility for interfacing with various field devices. The outputs are 24 VDC sourcing type with a maximum output current of 100 mA per output. Additionally, this module features one encoder counter input with a maximum frequency of 4 MHz. It is also known by the designation LIO-02.
Key Characteristics:
- Digital Inputs: 16 channels, 24 VDC sinking/sourcing configurable.
- Digital Outputs: 16 channels, 24 VDC sourcing, 100 mA maximum output current per channel.
- Encoder Counter: 1 channel, maximum count frequency of 4 MHz.
Product Parameters:
- Manufacturer: YASKAWA
- Part Number: JAPMC-IO2301-E
- Designation: LIO-02
